- 6 -
PU-2294A/B
PU-2325A
21 331-2637-00 MECH BRKT 1
22 313-1750-00 HEAT SINK 1
23 716-1831-00 REAR BOLT 1
24 345-4847-01 STOPPER 1
25 929-0069-83 CD MECHANISM 1
26 310-1669-02 UPPER CASE 1
27 716-0878-00 IT-SCREW(2.6×5) 2
28 731-3008-40 TAPTIGHT(M3×8) 2
29 714-2610-81 MACHINE SCREW(M2.6×10) 2
30 380-5439-00 KNOB 1
31 940-7862-64 ESCUTCHEON ASSY 1
(PU-2294A/B)
940-7892-63 ESCUTCHEON ASSY
(PU-2325A)
32 331-2573-00 SHIELD CASE 1
33 331-2578-00 SHIELD CASE 1
34 309-0720-02 FRONT PLATE 1
35 286-8497-26 SETPLATE(PU-2294A) 1
286-8497-27 SETPLATE(PU-2294B)
286-8497-28 SETPLATE(PU-2325A)
36 716-0778-00 WAVE SCREW(φ2×6) 4
37 013-3741-11 SWITCH 18
38 016-0010-13 VARIABLE RESISTOR 1
39 017-0454-01 PILOTLAMP 5
(PU-2294A/ORG/14V40mA)
017-0454-02 PILOTLAMP
(PU-2294B/GRN/14V40mA)
017-0454-03 PILOTLAMP
(PU-2325A/ORG/14V40mA)
40 074-1151-18 OUTLET SOCKET(18P) 1
41 816-2488-00 FLAT WIRE 1
42 714-2303-81 MACHINE SCREW(M2.3×3) 5
43 331-2593-00 LCD HOLDER 1
44 335-5994-00 SHIELD SHEET 1
45 379-1155-41 INDICATOR 1
(PU-2294A/PU-2325A)
379-1155-40 INDICATOR(PU-2294B)
46 335-5911-01 FILTER(PU-2294A/PU-2325A) 1
335-5912-01 FILTER(PU-2294B)
47 335-5910-00 ILLUMI PLATE 1
48 335-5909-00 LCD HOLDER 1
49 331-2638-00 SHIELD CASE 1
50 331-2639-00 SHIELD CASE 1
51 285-1633-10 GUIDE LABEL(CLASS1) 1
52 345-8316-00 INSULATOR 1
53 345-3814-82 LAMP CAP(PU-2294A/ORG) 2
345-3814-81 LAMP CAP(PU-2294B/GRN)
345-3814-83 LAMP CAP(PU-2325A/ORG)
54 017-0455-00 PILOTLAMP(9V65mA) 2
55 285-1628-00 GUIDE LABEL 1
56 285-1627-00 GUIDE LABEL 1
57 347-6200-00 INSULATOR 1
58 347-6217-00 INSULATOR(PU-2294A/B) 1
NO. PART NO. DESCRIPTION Q'TY
CD mechanism section:929-0069-83
1 HBS-463-100 DRIVE UNIT 1
1-1 966-0314-21 STOP LINK ASSY 1
1-2 966-0447-22 DR-PLATE ASSY 1
1-3 966-0448-21 SIDE PLATE ASSY 1
1-4 966-0449-22 CLAMP LINK ASSY 1
1-5 969-0050-51 PICK UP UNIT 1
1-6 013-7100-00 LIMIT SWITCH 1
1-7 620-0198-03 CLAMPER PLATE 1
1-8 620-0491-03 SPRING PLATE 1
1-9 620-0690-01 RATTLE PLATE 1
1-10 621-0205-02 CLAMPER LINK 1
1-11 621-0251-03 ROCK LINK 1
1-12 621-0252-03 DISC STOPPER 1
1-13 621-0253-02 MOTOR HOLDER 1
1-14 621-0255-02 SECOND GEAR 1
1-15 621-0375-00 SH-BASE 1
1-16 621-0357-03 PICK UP GUIDE 1
1-17 621-0358-02 LS-HOLDER F 1
1-18 621-0359-02 LS‐HOLDER R 1
1-19 622-1073-02 CLAMPER ROLLER 1
1-20 714-2003-81 MACHINE SCREW(M2×3) 10
1-21 716-0675-00 SCREW(M2×2.5) 2
1-22 716-1468-00 SCREW(M2×2.5) 2
1-23 716-1555-00 WAVE SCREW 1
1-24 716-1733-00 SCREW(M2×2.5) 2
1-25 732-2004-11 SEMS SCREW 2
1-26 739-1735-17 PRECISION SCREW 2
1-27 746-0761-00 SCREW(M2×2.5) 2
1-28 750-3097-03 CLAMPER SPRING 1
1-29 750-3098-00 L-LINK SPRING 1
1-30 750-3099-00 ES-SPRING 1
1-31 816-2372-00 WIRE(BLU) 1
1-32 816-2373-00 WIRE(WHT) 1
1-33 966-0454-00 SH-ROCK ASSY 1
1-34 HBS-432-100 LS-GEAR ASSY 1
1-35 SMA-146-100 SLED MOTOR ASSY 1
1-36 SMA-151-100 SPINDLE MOTOR ASSY 1
2 966-0308-10 CHASSIS ASSY 1
3 966-0309-20 L-DISC-G-ASSY 1
4 966-0310-21 SHIFT-P-CH-ASSY 1
5 966-0312-21 SHIFT-P-ASSY 1
6 966-0358-21 DRIVE-L-PL-ASSY 1
7 966-0359-21 SIDE-L-PL-ASSY 1
8 013-3879-01 CHUCKING SWITCH 1
9 039-0586-01 CHUCKING SWITCH PWB 1
(WITHOUT COMPONENT)
10 039-0588-01 SENSOR PWB 1
(WITHOUT COMPONENT)
11 060-0252-01 PHOTO TR (PT4850F) 3
12 345-7513-01 CLAMPER SHEET 1
13 345-7514-00 S-PWB SHEET 1
14 620-0485-04 FRONT PLATE 1
NO. PART NO. DESCRIPTION Q'TY
To Next Page
