Clarion SSW1001 User Manual

7
Sealed
Enclosure Airspace = 0.5 ft
3
net
Qtc = 0.721 F3 = 45.22Hz
Vented
Enclosure Airspace = 1.0 ft
3
net
Vent = 2.5” diam. x 12.79” long
Fb = 30Hz F3 = 25.11 Hz
Subwoofers – SSW1001 Information
• Composite Cone Design
• Powder Coated Damped Aluminum Basket
• Rubber Surround
• Dual Conex Spider
• 4-Layer CCAW Voice Coil
• 3” Black Anodized ASV coil former
• Dual 4-Ohm Voice Coils
• Dual Strontium Ferrite Magnets
• Oversized tinsel leads
• Gold-Plated Push Type Terminals
• S.E.T. (Spider Exhaust Technology) cooling
• Bumped and Vented T-Yoke
• Injection-moulded rubber mounting gasket
• Custom Tooled Magnet Boot
Maximum Power Handling . . . . . . . . . . . . . . . . . . . . 2000W
Continuous Power . . . . . . . . . . . . . . . . . . . . . . . . . . .1000 W
Frequency Response . . . . . . . . . . . . . . . . . 17 Hz to 800 Hz
Woofer Cone Material . . . . . Glass Fiber with PMI foam core
Woofer Magnet . . . . . . . . . . . . . . . . . . . . . . .Strontium Ferrite
Woofer Basket. . . . . . . . . . . . . . . . . . . . . . . . Cast Aluminum
Woofer Surround . . . . . . . . . . . . . . . . . . . . . . . . Butyl Rubber
Max Peak Music Power 2,000 W
Max Power 1,000 W
Nominal Impedance 2 or 8 Ohms
Fs (Hz) 33.5
Qms 4.27
Vas (Ft3 / Litre) 0.533 / 15.1
Mms (grams) 190.7
Xmax (mm) 24
Sd (Sq. M) 0.03
Qes S/P 0.753 / 0.753
Re S/P (Ohms) 6.4 / 1.6
Le S/P (mH) 1.517 / 6.067
Bl S/P (Tm) 18.47 / 9.236
Qts 0.64
2.8 V SPL S/P (dB) 80.66 / 87.75
no S/P (%) 0.073
Vd (ft3 / Liter) 0.071 / 2.0
Mounting Depth (mm) 177
Outside Diameter (mm) 277
Cutout Diameter (mm) 230
