Clark CQ 20 D - Major Component Locations

7-8 Major Component Locations
Major Component Locations
Use the illustration below to help locate components included in the
PM procedures.
The truck shown above is a typical representation of a Clark internal
combustion lift truck. Your model may vary slightly.
1
2
3
4 5 6
7
11
12
8
910
1. Engine Cooling
2. Transmission Cooling
3. Steer Axle
4. Engine
5. Transaxle
6. Wheels and Tires
7. Frame and Counter-
weight
8. Overhead Guard
9. Exhaust
10. Carburetion
11. Sheet Metal
12. Upright and Carriage
