2-18
Know your Tow Tractor
Parking brake
• The parking brake is released
by pushing the button on top
of the lever and then by mov-
ing the lever forwards.
Battery Specifications
The information on the battery specifications is printed on the
label affixed to the battery.
See below for the specifications of the batteries for Tow Tractor
models.
Batteries with higher capacity or additional functions, other
than those specified in the table above, are available.
However, the outer dimensions must be observed. A different
battery weight can affect the stability of the Tow Tractor.
Therefore, use a battery whose weight falls within the
allowable weight for the Tow Tractor.
Model Specification (standard) Dimension (L x W x H)
CTX40 48V, 230AH 830 x 414 x 624
CTX70 48V, 300AH 830 x 414 x 624
