Specification
General Information
1 Manufacture CLARK CLARK
2 Model Manufacture's Designation CTX40 CTX70
3 Rolling Load Capacity lbs(kg) 8800(4000) 15400(7000)
4
5 Power Unit 48 Volt 48 Volt
6 Operator Type Electric Rider Rider
7 Tire Type
Solid Pneumatic Solid Pneumatic
8 Wheels (x=driven) Front/Rear 1 / 2X 1 / 2X
Basic Dimensions
15 Overall Dimensions
17 Width Over Frame b1 in(mm) 39.2(995) 39.2(995)
18 Length w/Hitch, w/o Hitch l1 in(mm)
72(1830),68(1730) 72(1830),68(1730)
19 Coupling Height h10 in(mm) 11.6(295) 11.6(295)
20 Height, Weather Endosure h6 in(mm) 80.1(2035) 80.1(2035)
21 Step Height Ground to Topof Step Plate in(mm) 18.5(470) 18.5(470)
22.1 Loading Height
Ground to Car go Area(unloaded)
h11 in(mm) 23.8(605) 23.8(605)
22.2 Length of Loading surface l3 in(mm) 16.5(420) 16.5(420)
22.3 Width of Loading surface b9 in(mm) 30.2(767) 30.2(767)
23 Turning Radius Turning Radius Wa in(mm) 67(1700) 67(1700)
24 Inside Turning Radius b13 in(mm) 21.7(550) 21.7(550)
25 Overhang l5 in(mm) 12.2(310) 12.2(310)
26 Seat Height
Ground to top of Seat Cushion
h7 in(mm) 36.2(920) 36.2(920)
27
Performance
28 Speeds Travel Speed,Max w/Load mph(kph) 5.6(9) 4.3(7)
29 Travel Speed,Max w/oLoad mph(kph) 8.1(13) 10.6(17)
30
31
34 Service Weight lbs(kg) 2006(910) 2315(1050)
Weights
35 Axle loading Unload, Front/Rear lbs(kg)
860(390)/1147(520)
948(430)/1367(620)
Unloaded, Rear lbs(kg) 1146(520) 1367(620)
Chassis
39 Tires Number, Front/Rear 1/2 1/2
40 Size, Front in(mm) 4.00-8/6 4.00-8/6
Size, Rear in(mm) 4.00-8/6 4.00-8/6
41 Wheel base y in(mm) 45.6(1160) 45.6(1160)
42 Track Rear b11 in(mm) 34.25(870) 34.25(870)
43
44 Ground Clearance At Center of Wheel base m2 in(mm) 3.54(90) 3.54(90)
45 Driver Motor Rating S2-60m HP(kW) 8(6.0) 8(6.0)
46 Service Brake
Regen/Drum&Shoe Regen/Drum&Shoe
Driver Line
48 Battery Type Lead-Acid Lead-Acid
Weight, Min lbs(kg) 882(400) 1191(540)
Drive Motor Control AC inverter AC inverter
Max Capacity (6 hr rated) kWh 14.0 14.0
57 Towing Coupling Type Pin Type Pin Type
58 Sound Level ANSI B56.11.5 dB(A) 68.4 69.5
