Front Panel & LEDs
There are Light-Emitting-Diodes (LEDs) located on the front panel to indicate the status information of cable modem.
NAME
TEL2/TEL1 Green
WPS
Blinking
On
Off
WPS in paring
WPS enabled
WPS disabled
Blue
WLAN 5GHz
On
Off
Blinking
Wi-Fi enable
Wi-Fi disable
Data in traffic
On
Off
Blinking
TEL on-hook
TEL disable
TEL provisioning or off-hook
Green
On
Off
Blinking
Wi-Fi enable
Wi-Fi disable
Data in traffic
Green
LAN
Blinking
On
Off
Data in traffic
ETH device connected (GbE mode)
No ETH device connected
Green
ONLINE
Blinking
On
Off
Data in traffic
ETH device connected (FE mode)
No ETH device connected
Orange
Blinking
On
Off
CM provisioning
CM On-line
CM Off-line
Green
PWR
On
Off
DC Power is connected
No DC Power connected
Green
COLOR MODE STATUS
Blinking
On
Off
Downstream scanning
Downstream locked
Cable interface idle or W/DS bonding
Blue
On
Off
W/DS locked
W/DS disabled
Green
DS
Blinking
On
Off
Upstream scanning
Upstream locked
Cable interface idle or W/US bonding
Blue
On
Off
W/US locked
W/US disabled
Green
US
