18
-------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------
4) (EXTRACTION FUNCTION ONLY) Connect the coupling to the top of the
cooker ho
od (see below). Then connect
the discharge pipe to the coupling as
shown below. Remember that your ducting will have to match the
specifications shown in the notes on Extraction / Air Purifier (Recirculation)
Modes on p.18.
INSTALLATION INSTRUCTIONS – Attaching the Hood
