21
Remove the metal grease filters from the hood
Slacken both anchoring screws “F”
Place the glass ‘Q’ on the upper shelf of the hood, pushing it in
towards the wall.
Tightening the screws ‘F’ again in the hole and connecting them to
the unit.
Take care that the anchoring corner is firmly fastened, tightening it
well.
Re-insert the ventilation tube with the coupling tube ‘N’.
PLEASE NOTE * DO NOT OVERTIGHTEN THESE SCREWS OR YOU
MAY DAMAGE / DISTORT THE UNIT.
ATTACHING THE GLASS
