CLEAR DESIGN BLADE BBC1 - Attach Flat Brackets to Main Surface

24
END OF 66" W RETURN OR LARGER SECTION
3"
1"
16.25"
10B | ATTACH FLAT BRACKETS TO MAIN SURFACE
Attach flat brackets to main surface using wood screws. See dimensions below
for bracket placement. For surfaces 72" or larger, secure support bar to center of
the main surface. Insert wood screws through support bar and into underside of
surface. Tighten the screw on main profile beam.
