CLEAR DESIGN BLADE BBC1 - Secure Bracket to End Legs

41
LAMINATE INSET END PANELS
1 | SECURE BRACKET TO END LEGS
Attach 4 brackets to each BLADE end leg using the self-tapping screws.
1. Inset–The back of the bracket will align flush with edge of leg.
2. Flush–Back of bracket will be 9/16" from edge back edge of leg.
9
/
16
"
Align Flush
Align Flush
Flush Bottom View
Inset Bottom View
