CLEAR DESIGN BLADE BBC1 - Page 5

2
54" W RETURN OR SMALLER
CODE QTY DESCRIPTION
GB3072 1
Surface 30"x72"
GB2448 1
Return Surface 24"x48"
BB3
1
Extra Long Beam
2
Lock Plate
4
Cap Screw
1
Locking Screw and Lever
BL30
2
BLADE 30" End Leg
12
Wood Screws
BL24
1
BLADE 24" End Leg
6
Wood Screws
BASB72
2
42" Support Bar•
20
Wood Screws
BFB1 2
Flat Bracket
PARTS LIST
*Support bars will be added to surfaces 72" and longer. If working with a
60" W return, skip to page 7.
