Assembly Instructions Cont’d
The side wall panels connect to the back wall with the installed locking brackets. There are mating brackets on the side
of each panel.
1. Place the right back wall in the slot in the oor.
Li the right back wall up about 4” (10cm)
higher than the le back wall panel
(See Picture 1).
2. Place the right back wall panel against the le
back wall (See Picture 2), then slide down the
right back wall panel until the two panels are
equal height. (See Picture 3).
3. If the panels are not equal height or there is
an obvious gap between the two panels, this
means they are not propery attached and you
should try again.
4 - CONNECT SIDE WALLS
