73
SANCTUARY C
Assembly Instructions Cont’d
7 - CONNECT HEATER CONNECTION UNDER BENCH
1. Set the wood portion of the roof on the back roof
guide. Besure to slide the roof back against the back
wall.
9 - INSTALLING WOOD PORTION OF ROOF
1. The side walls must be secured to the back wall and wood roof piece using the attached eye hooks.
2. Screw in one of the eye hooks between the left side wall and backwall and one between the right side
wall and backwall.
10 - INSTALLING WALL LOCKS
THIS STEP IS VERY IMPORTANT.
PLEASE DO NOT OMIT THIS STEP.
Attach the eye hook so that it is
screwed into side walls and the wood
roof piece.
Attach eye hook so that it is screwed
into both the side walls and back
walls.
To Next Page
