75
SANCTUARY C
Assembly Instructions Cont’d
13 - INSTALLING LEFT SIDE GLASS WINDOW
Left Front Wall Installed
3. Secure the outer-most Side Wall-Mounted L Shape
Brackets into the wall using the screws provided.
Wall
Bracket
Glass Ceiling
Glass Panel
12 - INSTALLING GLASS DOOR AND RIGHT SIDE GLASS WINDOW
1. Open the door of the sauna to allow room to place the left side glass window.
2. Place the left side glass window and push it against the left side wall so it is securly in place. Until this
piece is secured using the included brackets, someone should hold the piece in place.
3. Secure the left front glass window to the roof glass using the included brackets. You will see pre-drilled
holes in both the front glass and roof glass.
4. Secure the outer-most Side Wall-Mounted L Shape Brackets into the wall using the screws provided.
Wall
Bracket
Glass Ceiling
Glass Panel
To Next Page
