41
SANCTUARY 3
Assembly Instructions Cont’d
1. We recommend using two people to move
the glass door and right window piece.
Place the glass door with left window in
the groove in the oor and slide it securely
into place against the left wall. It may help
to put the corner of the glass in place rst
then put the rest of the glass in the slot.
Until this piece is secured as in step 2 below
using the enlcosed brackets, please hold
this piece in place.
2. Secure the lef side glass window to the
roof glass using the included brackets.
You will see pre-drilled holes in both the
front glass and roof glass. One person
should hold the outside piece while the
other person screws in the bolt.
11 - INSTALLING LEFT SIDE GLASS WINDOW
1. The side walls must be secured to the back wall and wood roof piece using the attached eye hooks.
2. Screw in one of the eye hooks between the left side wall and backwall and one between the right side
wall and backwall.
10 - INSTALLING WALL LOCKS
THIS STEP IS VERY IMPORTANT.
PLEASE DO NOT OMIT THIS STEP.
Front Wall Installed
Attach the eye hook so that it is screwed into
side walls and the wood roof piece.
Attach eye hook so that it is screwed
into both the side walls and back walls.
x2
x2
x4 x6 x6
x2
To Next Page
