59
SANCTUARY Y AND SANCTUARY RETREAT
Assembly Instructions Cont’d
10 - INSTALLING RIGHT SIDE GLASS WINDOW
1. We recommend using two people to move the glass door and right window piece. Place the glass door
with left window in the groove in the oor and slide it securely into place against the left wall. It may
help to put the corner of the glass in place rst then put the rest of the glass in the slot. Until this piece
is secured as in step 2 below using the included brackets, please hold this piece in place.
2. Secure the lef side glass window to the roof glass using the included brackets. You will see
pre-drilled holes in both the front glass and roof glass. One person should hold the outside piece
while the other person screws in the bolt.
Door and Right Front Wall Installed
x2
x2
x4 x6 x6
x2
3. Secure the outer-most Side Wall-Mounted L Shape
Brackets into the wall using the screws provided.
Wall
Bracket
Glass Ceiling
Glass Panel
To Next Page
