SANCTUARY 1
Assembly Instructions Cont’d
The side wall panels connect to the back wall with the installed locking brackets. There are mating brackets
on the side of each panel.
1. Place the left side wall in the slot in the
oor. Lift the side wall up about 4” (10cm)
higher than the backwall panel (See Picture
1).
2. Place the side wall panel against the back
wall (See Picture 2), then slide down side
wall panel until the two panels are equal
height. (See Picture 3).
3. If the panels are not equal height or
there is an obvious gap between the two
panels, this means they are not propery
attached and you should try again.
4. Repeat the steps above for the right side
wall panel.
4 - CONNECTING SIDE WALLS
Picture 1 Picture 2 Picture 3
Right Side Wall InstalledLeft Side Wall Installed
If the panels still seem too tight to
come down all the way, try backing o
the bracket screws by one half turn
with a Phillips head screwdriver on the
female bracket.
