8

Compare the ozone system equipment received to the packing list provided.
Before beginning any installation procedures, thoroughly inspect all
components for damage. If damage is noticed, promptly notify the freight
carrier and request an on-site inspection. Inspect all packing materials for small
parts before discarding. Inspect all plumbing, ttings and tubing for packing
material that may have become lodged in openings.

When placing the ozone system components in the equipment room, make sure to consider safety,
maintenance requirements, local building and re codes, etc. The components should be easily
accessible by the operators, including equipment access doors and electrical hook-up boxes. All
meters, gauges, indicator lights and switches should be visible and accessible. Dimensional drawings
of each air preparation system and ozone generator are included in Section A of the Appendix.
The air preparation system and ozone generator should be located as close as possible to the point
of ozone injection. Ozone is an unstable gas and will begin reverting back to oxygen very quickly.
To determine the most favorable ozone injection point, the following items should be considered:
• Located downstream of all other existing water system components.
• Located upstream of the residual sanitizer injection point (if so equipped).
• In a Sidestream plumbing conguration (see Figure 5-1) with recirculation, the pH adjustment
chemical injection point must be located downstream of the residual sanitizer injection point
(if so equipped).
• In a Full Flow plumbing conguration (see Figure 5-2) without recirculation, locate
downstream of the pH adjustment chemical injection point
Adequate protection from weather, dust and excessive heat.
Like any electronic component, performance and longevity is enhanced by favorable operating
conditions. Also, since each air preparation system and ozone generator is air-cooled, a relatively
dust-free, well ventilated area is required. No caustic chemicals should be stored in the area
surrounding the equipment. A minimum clearance of six inches from the vents on either side of the
ozone generator is required.
The equipment is heavy and requires proper support. Therefore, a clean, dry, level surface should be
provided for the air preparation system and ozone generator. These components should be securely
fastened to the surface using the mounting holes and/or tabs provided.
The air preparation system and ozone generator are not designed to withstand outdoor elements,
including direct contact with water and/or temperature extremes. Therefore, the equipment must be
installed in an environment consistent with the following operating parameters:
Ambient temperature range: 20°F to 85°F continuous. If the temperature around the
equipment
consistently exceeds 85°F, additional air cooling must be provided.
Humidity: 0 – 90% relative humidity, non-condensing environment
Line voltage: +/-10% of rated input
Note: Equipment installed in extreme environmental conditions will void manufacturer's warranty.
Allow room for the peripheral equipment (booster pump, injector manifold, contact vessel, etc.).
Getting Started
