Page 11
Posi-Twist (A):
1. Strip all wires to be inserted 3/4”.
2. Twist all wires together.
3. Completely unscrew the top from the Posi Twist.
4. Feed the twisted wires through the bottom portion of the Posi-Twist.
5. While ensuring the wires do not slip out of the bottom of the Posi-Twist,
attach the top and tighten.
Posi-Tap (B):
1. Unscrew the cap of the Posi-Tap (gray or large end).
2. Slide the wire you wish to tap into through the slot in the cap.
3. Re-attach the body of the Posi-Tap and tighten.
4. Attach the other wire to the bottom using the same method as a Posi-Twist.
Posi-Lock (C):
Attach the wires to the screw in connectors using the same method as
Posi-Twists.
A B C
Posi-Products Installation Instructions:
Notes:
