29
Final assembled
model
26
The worm screw for lifting
1:1
3
Technical and scientific
analysis
Technically called an involute,
the worm screw is a cylindrical
helical gear.
In a worm-and-gear set, the
former is called the ‘driver’,
because motion can only be
transferred from the worm
screw to the gear and not
vice-versa. The worm screw
can therefore be used to lock
the mating gear in a certain
position.
3
18
10
2
2
2
1:1
2
Assembled stand
Stand assembled
in the pre-activity task
X3
2
3
X1
X6
X2
X1
X1
X1
10
X1
18
