Clever MA 360 - Page 5

4
Specications MA 360 MA 3120 MA 3240
Power output: 60Wrms / 75W peak 120Wrms / 135Wpeak 240Wrms / 255Wpeak
Speaker outputs: 50V, 70V, 100V &
4-16Ω
50V, 70V, 100V &
4-16Ω
50V, 70V, 100V &
4-16Ω
Microphone inputs: 4 x XLR balanced
with phantom power
4 x XLR balanced
with phantom power
4 x XLR balanced
with phantom power
Sensitivity: -50 / -2dB, 2.5 /
500mV
-50 / -2dB, 2.5 /
500mV
-50 / -2dB, 2.5 /
500mV
S/N ratio: >68dB >68dB >68dB
Frequency response:
40Hz-17kHz (±3dB) 40Hz-17kHz (±3dB) 40Hz-17kHz (±3dB)
Phantom power: +48V +48V +48V
4 Auxiliary inputs:
Tuner and tape inputs
(sensitivity/imped-
ance):
200mV / 47kΩ 200mV / 47kΩ 200mV / 47kΩ
CD and line inpute
(sensitivity/imped-
ance):
500mV / 47kΩ 500mV / 47kΩ 500mV / 47kΩ
S/N ratio: 90dB 90dB 90dB
Frequency response: 40Hz-18kHz 40Hz-18kHz 40Hz-18kHz
Control:
Bass:
±12dB ±12dB ±12dB
Treble:
±12dB ±12dB ±12dB
Chime: 2 tone and 4 tone
options
2 tone and 4 tone
options
2 tone and 4 tone
options
Outputs:
Output level/imped-
ance:
775mV / 47kΩ 775mV / 47kΩ 775mV / 47kΩ
Output REC/imped-
ance:
200mV / 1kΩ 200mV / 1kΩ 200mV / 1kΩ
Distorsion: <0.1% <0.1% <0.1%
Cooling: Fan cooled Fan cooled Fan cooled
Power consumption: 100W 200W 400W
DC power supply: 24V 24V 24V
AC power supply: 240V-50Hz 240V-50Hz 240V-50Hz
Dimensions (H x W
x D):
88 x 484 x 353mm 88 x 484 x 353mm 88 x 484 x 353mm
Weight: 10.1kg 10.9kg 17.9kg
Order code: CRAM07 CRAM08 CRAM09
