Slide Connection Rod (E) rst through the outer
Thick Slat (C). Proceed to thread Connection
Rod (E) through Back (B) planks. Alternate
sliding the rod through Thin Slat (D) and plank.
You will end with the rod going through the
remaining Thick Slat (C).
NOTE: You may need to slightly raise BACK (B)
portion to easily insert rod.
CAUTION: TO AVOID INJURY DO NOT PUT YOUR HAND OVER THE HOLE AS YOU ARE
THREADING THE CONNECTION ROD THROUGH
8
Hand tighten
Endcap Screw (F)
Tighten all hex bolts in the 4 exposed
holes using the Hex Wrenches (I). Then
insert plugs (H) to cover exposed holes on
the Back (B) and Seat (A) portion of chair.
Sit, relax, and enjoy your new Tamarack Chair.
2556 Gateway Road Carlsbad, California 92009
760.814.3577
info@clevermade.com
www.clevermade.com
Stand up chair & tighten
all Endcap Screws (F)
with both Allen Wrenches
(G) - one to secure and
one to tighten.
9
11
12
10
Back (B)plank
Slats
