Clevo NP71PNP User Manual

Disassembly
2 - 6 Removing the Battery
2.Disassembly
4. The battery will be visible at point on the computer (Figure 2c).
5. Carefully disconnect the cable , then remove screws
- (Figure 2d).
6. Lift the battery off the computer (Figure 2e
).
7. Reverse the process to install a new battery (do not forget to replace all the screws and the bottom cover).
16
17
18
22
23
Figure 2
Battery Removal
(cont’d.)
c. Locate the battery.
d. Disconnect the cable and
remove the screws.
e. Lift the battery off the
computer.
d.
e.
23
18
17
c.
16
19
20
22
21

23. Battery
•5 Screws
