Disassembly
Wireless LAN, Combo, 3G & LTE Module Cables 2 - 17
2.Disassembly
Wireless LAN, Combo, 3G & LTE Module Cables
Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are
not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden-
tification as outlined in the table below.
Cable 1 is usually connected to antenna 1 (Main) on the module, and cable 2 to antenna 2 (Aux).
Removing the 3G/4G Module
Module Type
Antenna
Type
Cable Color
Cable Cover
Type
WLAN/WLAN & Bluetooth
Combo
WM 1
Black
Transparent
WM 2 White
LTE Broadband
LTE 1
Black
Black
LTE 2 Blue
3G Broadband
3G 1
Black
Black
3G 2 Blue
To Next Page
