8 / 19User Manual
Put a washer under each screw and
loosely screw in all four screws. When
all four screws are loosely screwed in,
tighten all screws one by one.
Check the screws each time before
snowboarding to ensure that they are
tightened and undamaged.
!
Do not use any type of Loctite or similar
products which can critically reduce the
strength of plastic parts.
5
Line up the holes with the inserts in
your board and then find your pre-
ferred angle by rotating the binding
under the disc.
To read the angle, see where the
marks on the binding line up with
the angle marks on the disc.
!
Most riders in our team set their binding
angles to around 15° on their front foot
and -9° on their back foot.
3
The CLEW binding can be used with
the hole patterns shown above.
!
If your board has a 3D hole pattern,
you will need a special mounting disc,
which we provide free of charge.
In this case, contact CLEW Support
(support@clew.de).
4
!
