Handle installation
To install the handle provided with your wine cellar, please follow the below instructions:
1) Pull away the door gasket in the area where the handle has to be installed; you can see two designated
holes for the handle installation. The gasket is easily displaced by hand, no tools are necessary.
2) Install the handle tightly as shown above with two screws. Be caution; do not over tighten as it will cause
damage to the handle assembly or surface of glass door.
3) Replace the door gasket to its original position. Make sure it will be well positioned and maintains perfect
hermiticity.
Reversing the door
The door can be changed from left and right side. No special requirement, all the door is opened from left
side. If required to open from right side please refer to the following direction.
Note: all parts removed must be saved to do the reinstallation of door.
