Reversing the door
The instruction is based on a unit with right door hinge installed already. To reserve the door from right
hinge to left hinge, you need to get ready 2 new spare parts: an upper left hinge, and a bottom left hinge.
All removed parts must be saved to do the door reinstallation, except those remarked with “disused”.
1. Open the door, and loosen the 2 screws ① and ②. See Figure 1.
2. Carefully remove the door from the upper right hinge ④ and prevent it from scratching. Take out the
support rod ③ from the door hinge hole. See Figure 2.
3. Pull out the 6 decorating plastic bolts covering the reserved hinge screw holes at the front left corner of
the cabinet.
4. Unscrew the upper right hinge ○,4(Disused) and bottom left hinge ○,6 (Disused) from the cabinet. See
Figure 3.
5. Install the upper left hinge ○,7and bottom left hinge○,8 to the left side of the cabinet. Make sure the
screws are tightened. See Figure 4.
6. Put upside down the door and install it to the left hinges by following the opposite steps of taking down
of the door as described above
7. Cover the hinge screw holes on the right side with the 6 decorating plastic bolts.
