Enhanced safety:
Since this range of appliances is intended for storing items of value, we have been careful to select quality
components and to design suitable manufacturing techniques to ensure optimum safety in operation.
Installing the handle:
Your appliance has a stainless-steel handle. To fit it, simply screw it onto the door with the screws supplied as
per the diagram below, having first removed the seal.
Reversing the door:
The instruction is based on a unit with right door hinge installed already.
To reserve the door from right hinge to left hinge, you need to get ready 2 new spare parts: an upper left hinge,
and a bottom left hinge.
All removed parts must be saved to do the door reinstallation, except those remarked with “Disused”.
1 Open the door, and loosen the 2 screws ① and ②. See Figure 1.
2 Carefully remove the door from the upper right hinge ④ and prevent it from scratching. Take
out the support rod ③ from the door hinge hole. See Figure 2.
3 Pull out the 6 decorating plastic bolts covering the reserved hinge screw holes at the front left corner of
the cabinet.
4 Unscrew the upper right hinge
○
,4(Disused) and bottom left hinge
○
,6 (Disused) from the
cabinet. See Figure 3.
5 Install the upper left hinge
○
,7and bottom left hinge
○
,8 to the left side of the cabinet. Make
sure the screws are tightened. See Figure 4.
6 Put upside down the door and install it to the left hinges by following the opposite steps of
taking down of the door as described above
7 Cover the hinge screw holes on the right side with the 6 decorating plastic bolts.
G a s k e t
F la t Washer
