Climadiff CLIMA7K1 - Description of the Appliance

37
2. DESCRIPTION OF THE APPLIANCE
Control panel
Horizontal and vertical louver control lever
(adjust manually)
Note: CLIMA5K1 not adjustable
Air conditioner
caster
front
Handle (both sides)
Air filter
Upper air intake
Drain outlet
Air outlet
Lower air intake
Bottom tray drain outlet
Arrière
