ACP Air/water inverter heat pumps with axial fansi
25












 Model



230V / 1ph ACP06 / ACP08 3 x 4 mm² L/N: 3,4 Nm – PE: 1 Nm
230V / 1ph ACP12 3 x 4 mm² L/N: 3,4 Nm – PE: 1 Nm
230V / 1ph ACP14 3 x 6 mm² L/N: 3,4 Nm – PE: 1 Nm
400V / 3ph ACP12T 5 x 2,5 mm² L1/L2/L3: 3,4 Nm – N/PE: 1 Nm
400V / 3ph ACP14T 5 x 2,5 mm² L1/L2/L3: 3,4 Nm – N/PE: 1 Nm


User terminal block




TERMINAL CONNECTION TYPE
X-1 Connect the ground cable
Inlet for power supply 1-Ph/N/PE,230 V, 50 Hz
(only for models 06/08/12/14)
N Connect the neutral cable from the mains
L Connect the phase cable from the mains
PE Connect the earth cable
Input for power supply 3-Ph/N/PE, 400 Vac,
50 Hz.
(only for models 12T and 14T)
N Connect the neutral cable from the mains
L1 Connect the phase cable L1 from the mains
L2 Connect the phase cable L2 from the mains
L3 Connect the phase cable L3 from the mains
X-5.2 Connecon of modbus RTU signal + for remote keyboard
Modbus communicaon
X-5.1 Connecon of modbus RTU signal – for remote keyboard
X-4.1
Connecon of modbus RTU earth reference for remote
keyboard (GND)
X-12.1 Remote keyboard power supply (12 V, 50 Hz, 500 mA)
Output for power supply 12 Vac, 50 Hz
X-12.2 Remote keyboard power supply (12 V, 50 Hz, 500 mA)
X-17.1/X-17.2 DHW probe (SAS1) Analogue or digital input
X-19.1/19.2 Plant remote probe (SAS2) Analogue input
X-20.1/X-20.2 Double set point (Q4) Analogue input
X-22.2 0-10V (+) signal input to modify set point
Analog input (ST10)
X-22.1 0-10V (-) signal input to modify set point
X-6.1/X-6.2 Plant heater (Rimp)
Output in single phase voltage 230Vac, 50Hz,
5A resisve, 1A inducve.
Can be used in versions without KA
X-9.1/X-9.2 Exchanger heater (KAS)
Output in single phase voltage 230Vac, 50Hz,
5A resisve, 1A inducve.
Can be used in versions without KA
X-10.1/X-10.2 Base heater (KAB)
Output in single phase voltage 230Vac, 50Hz,
5A resisve, 1A inducve.
X-11.1/X-11.2 Domesc hot water valve outlet (VS1)
Changeover contact, single phase voltage
230Vac, 50Hz, 5A resisve, 1A inducve.
X-14.1/X-14.2 Double set-point valve output (VDIS1)
Changeover contact, single phase voltage
230Vac, 50Hz, 5A resisve, 1A inducve.
X-16.1/X16.2
Summer/winter mode change input from remote (to ac-
vate the funcon, see the relevant paragraph in the MCO
manual)
Voltage-free digital input
