YANMAR DIESEL ENGINE SPECIFICATIONS
Model YSE-8/YSE-8G
Type 4-cycle horizontal diesel engine
# of cylinders One
Bore x stroke 75 x 75
Displacement 0.331
Cont. Rating
Output HP/Rpm 5/2200 6/2600 7/3200
1-HR rating 8/3200
Reduction ratio 2/3
Direction of rotation-
Crankshaft Counter-clockwise (view from stern)
Propeller shaft Counter-clockwise (view from stern)
Compression ratio 23.1
Combustion System Special swirl precombustion chamber
Lubrication System Enclosed full pressure lubrication w/trochoid pump
Cooling System Water cooling w/rotary pump.
Starting System Electric w/manual combination
Gear System Reduction & reversing gear w/single
Disc plate mech. clutch (wet type)
Dry Weight kg (Ibs) 118 (260)
* Abo
ve mentioned HP indicates shaft horsepower.
