CLIVET CF 121

M42740M4-02 02/10/08 page 14
unit configuration :
with CTS CLIVET TERMINAL SPACE electronics
valve control – 4-pipe system
components supplied by the customer
valve control - 2-pipe system
components supplied by the customer
25
24
max 24 V
23
22
21
20
COOL
HEAT
gnd
gnd
gnd
0..10V
0..10V
25
max 24 V
21
20
COOL
HEAT
gnd
gnd
0..10V
heating elements (optional) fresh air damper (optional)
23
22
gnd
0..10V 20
19
400 / 3 / 50
L1 L2 L3
N
L2
SAE
