116
M0CZ00007-03
For each zone you can set the commands listed in the table below.
There are 7 records for each zone
Note: If mode zone = 0, The zone will follow the local programming set to CONTROL4 NRG (Or any area mode manual forcing)
Address Description Notes
140 System status 1 = off, 2 = on
141 System mode 1 = cooling, 2 = heating
142 Heat pump status 0 = off (or standby), 1 = system, 2 = DHW
143 Outdoor temperature
144 Heat pump alarm 0 = not alarm, 1 = alarm
145 Heat pump supply temperature
146 Compressor heat pump power 0…100% ((in tenths of %)
147 Heat pump working Setpoint
2.2 Status
For each zone you can read the data listed in the table below.
There are 4 records for each zone
1.2 Stata
2 - Zone
2.1 Commands
Zone 1 2 3 4 5 6 7 8 9 10 11 12
Offset 10 17 24 31 38 45 52 59 66 73 80 87
Address (es. zone 1) Description Notes Limits
Offset zone + 0 (10 + 0 = 10) Winter comfort Setpoint zone 8.0°C…35.0°C
Offset zone + 1 (10 + 1 = 11) Summer comfort setpoint zone 8.0°C…35.0°C
Offset zone + 2 (10 + 2 = 12) Delta winter setpoint eco zone
Positive value. In Eco mode will be subtracted from the
comfort Setpoint
0.1°C…15.0°C
Offset zone + 3 (10 + 3 = 13) Delta summer setpoint eco zone
Positive value. In Eco mode will be added to the comfort
Setpoint
0.1°C…15.0°C
Offset zone + 4 (10 + 4 = 14) Zone mode 1 = zone off, 2 = zone Eco, 3 = zone comfort
Offset zone + 5 (10 + 5 = 15) Winter humidity Setpoint zone 10%...90%
Offset zone + 6 (10 + 6 = 16) Summer humidity Setpoint zone 10%...90%
Zone 1 2 3 4 5 6 7 8 9 10 11 12
Offset 150 154 158 162 166 170 174 178 182 186 190 194
Address (es. zone 1) Description Notes
Offset zone + 0 (150 + 0 = 150)
Average temperature zone
Offset zone + 1 (150 + 1 = 151)
Average umidity zone
Offset zone + 2 (150 + 2 = 152) Profile zone 1 = zone off, 2 = zone on eco mode, 3 = zone on comfort mode
Offset zone + 3 (150 + 3 = 153) Setpoint zone
