117
M0CZ00007-03
Address Description Notes Limits
110 Setpoint reload DHW 25°C…55°C
111 Setpoint maintenance DHW 25°C…55°C
112 DHW profile
1 = Maintenance + recirculation, 2 = Maintenance,
3 = recirculation+ recharge, 4 = recharge
For each ElfoFresh (EF) you can set the commands listed in the table below.
There are zone 5 records for each ElfoFresh
3.2 Stata
Address Description Notes
200 DHW temperature
201 DHW second temperature
202 DHW profile
1 = Maintenance + recirculation, 2 = Maintenance,
3 = recirculation+ recharge, 4 = recharge
203 Solar temperature
204 Solar status 0 = disable, 1 = active
205 DHW pump/ Recirculation 0 = disable, 1 = active
206 Heating element/DHW boiler 0 = disable, 1 = active
207 Antilegionella
0 = not in progress, 1 = in progress
4.2 Stata
For each ElfoFresh (EF) you can read the data listed in the table below.
There are 9 records for each ElfoFresh
3 - Domestic Hot Water (DHW)
3.1 Commands
ElfoFresh 1 2 3 4
Offset 115 120 125 130
4 - ElfoFresh
4.1 Commands
Address (es. zone 1) Description Notes Limits
Offset EF+ 0 (115 + 0 = 115)
Winter Setpoint room temperature 18.0°C…26.0°C
Offset EF+ 0 (115 + 1 = 116)
Summer Setpoint room temperature 22.0°C…28.0°C
Offset EF+ 0 (115 + 2 = 117)
Winter room humidity Setpoint 5%…80%
Offset EF+ 0 (115 + 3 = 118)
Summer room humidity Setpoint 45%…100%
Offset EF+ 0 (115 + 4 = 119) Functionnning mode 1 = EF disabled, 2 = EF fan mode only, 3 = auto mode
ElfoFresh 1 2 3 4
Offset 210 219 228 237
Address (es. zone 1) Description Notes
Offset EF+ 0 (210 + 0 = 210) Room supply temperature
Offset EF+ 0 (210 + 1 = 211) Room return temperature
Offset EF+ 0 (210 + 2 = 212) Room air humidity
Offset EF+ 0 (210 + 3 = 213) Outdoor air temperature
Offset EF+ 0 (210 + 4 = 214)
Ambient air setpoint
Offset EF+ 0 (210 + 5 = 215)
Status 0 = off, 1 = on
Offset EF+ 0 (210 + 6 = 216)
Compressor 0 = off, 1 = on
Offset EF+ 0 (210 + 7 = 217)
Dehumidify 0 = not in progress, 1 = In progress
Offset EF+ 0 (210 + 8 = 218) Alarm 0 = not on alarm, 1 = alarm
