CLIVET CONTROL4 NRG - Page 43

43
M0CZ00007-03
BUS RS485
Blink Communication OK
Fixed Communication KO
Off Not feeded
ELECTRICITY METER - SINGLE PHASE
DIP position
Assembly on DIN rail
Electrical connections
Terminals side
A - Diagnostics LED
The energy value is acquired by the CONTROL4 NGR via a ModBUS serial communication line
