M0CZ00007-03
SYSTEM COMPONENT ADDRESSING
Enter the password Maintenance operator to access the parameters.
SPHERA EVO 2.0 EASYHYBRID
Parameters to be modified
Parameter
Mnemonic
Name
Description Value
101 Index
ModBus supervision serial
address
2
102 Baud Rate
Baud Rate (0=4800 / 1=9600
2 =19200)
1
103 Parity
Parity 0=NO / 1=Odd 2=Even
supervision serial
0
Press “Setting”
Enter the Password
Press Confirmation
Select “Parameters”
Press
Select “All”
Press
Select the parameter to be modified “101”
Confirm
Enter the value
Confirm the value entered
Set parameters 102 and 103.
Set password
CANCELL CONFIRMATION
SETTINGS
PARAMETERS
KEYBOARD
SYSTEM INFO
ALARMS
PDC - PARAMETERS
ALL
CONFIGURATION
DURATION COMPENSATION
