75
M0CZ00007-03
SYSTEM COMPONENT ADDRESSING
Enter the password Maintenance operator to access the
parameters.
ELFOFRESH EVO CPAN-YIN SIZE 2
Parameters to be modified
Parameter
Mnemonic
Name
Description Value
1.15 BmsAddSet ModBus serial address 3,4,5,6
if one unit is present:
address = 3
if four units are presents:
First unit address = 3
Second unit address = 4
Third unit adress = 5
Fourth unit adress = 6
WSAN-YMI 21-81 EDGE
Setting
Unit main board
S3 = 2
S3
Press MENU
Select “Assistance Setting”
▲ UP
▼ DOWN
Press
OK
Enter the PASSWORD
Press
OK
Select “Operation Parameter”
▲ UP
▼ DOWN
Press
OK
Select “1.15 BmsAddSet”
▲ UP
▼ DOWN
Edit value as indicated in the table
To Next Page
