CLIVET CONTROL4 NRG - Page 81

81
M0CZ00007-03
SYSTEM COMPONENT ADDRESSING
WSAN/T-XIN / WSN/T-XIN
Parameters to be modified
Parameters Description Value
CF30 ModBus protocol controller Address 2
CF31
ModBus protocol Baud Rate (2=4800 / 3=9600
4 =19200)
3
CF32 Parity modbus 1=EVEN / 2=NONE / 3=ODD 2
CL43
DI4 Digital input Configuration
( remote OFF)
-2
CL44
DI5 Digital input Configuration
(remote Summer / Winter )
0
Press
+
PAr
Press
CL
Select CF menu
/
CF
Press
CF01
Select CF30
/
CF30
Press
0
Set the value
/
2
Confirm
2
Back to the previous menu
Repeat the sequence for the other parameters
