3. INSTALLATION
Switch off the unit.
Multifunction board
Display
1) Open the indoor unit front panel
Remove screw
2) Install multifunction board in its housing
3) Install the Terminal board
Open the electrical panel
Terminal board housing
Terminal board inserted
