CLIVET WSAN-YMi 91 - General Technical Data; Performance Data; Construction Details

15 - General technical data
Performance
SIZE 81 91 101 121 141
Power supply 400/50/3+N
RADIANT PANELS
Heating
Heating capacity (EN 14511:2018)
1,9 kW
16,3 18,0 22,0 26,0 30,1
Total power input (EN 14511:2018)
1 kW
3,63 3,83 5,00 6,37 7,70
COP (EN 14511:2018)
2
4,49 4,70 4,40 4,08 3,91
ErP Space Heating Energy Class -
AVERAGE Climate - W35
8,11
A++ A+++ A+++ A+++ A++
SCOP - AVERAGE Climate - W35
10
4,30 4,60 4,53 4,50 4,19
Cooling
Cooling capacity (EN 14511:2018)
5,9 kW
15,5 18,5 23,0 27,0 31,0
Total power input (EN 14511:2018)
5 kW
3,63 3,90 5,00 6,28 7,75
EER (EN 14511:2013)
6
4,27 4,75 4,60 4,30 4,00
Water flow-rate
5 l/s
0,74 0,88 1,10 1,29 1,48
Useful pump discharge head
5 kPa
19,6 99,5 89,4 74,4 54,0
TERMINAL UNIT
Heating
Heating capacity (EN 14511:2018)
3 kW
16,2 18,0 22,0 26,0 30,0
Total power input (EN 14511:2018)
3 kW
4,70 5,14 6,47 8,39 10,3
COP (EN 14511:2018)
2
3,45 3,50 3,40 3,10 2,90
Cooling
Cooling capacity (EN 14511:2018)
7 kW
13,8 17,0 21,0 26,0 29,5
Total power input (EN 14511:2018)
7 kW
5,19 5,57 7,12 9,63 11,6
EER (EN 14511:2018)
6
2,66 3,05 2,95 2,70 2,55
SEER
10
4,54 4,70 4,70 4,66 4,49
Water flow-rate
7 l/s
0,66 0,81 1,00 1,05 1,10
Useful pump discharge head
7 kPa
30,7 102 94,6 78,8 59,4
RADIATORS
Heating
Heating capacity (EN 14511:2018)
4 kW
16,1 18,0 22,0 26,0 30,0
Total power input (EN 14511:2018)
4 kW
5,83 6,55 8,30 10,61 13,0
COP (EN 14511:2018)
2
2,76 2,75 2,65 2,45 2,30
ErP Space Heating Energy Class -
AVERAGE Climate - W55
8
A++ A++ A++ A+ A+
SCOP - AVERAGE Climate - W55
10
3,27 3,21 3,22 3,14 3,14
Water flow-rate
4 l/s
0,48 0,54 0,66 0,78 0,90
Useful pump discharge head
4 kPa
55,5 109 106 103 99,1
The Product is compliant with the Erp (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 811/2013 (rate heat output ≤70 kW at
specified reference conditions) and the Commission delegated Regulation (EU) No 813/2013 (rated heat output ≤400 kW at specified reference conditions).
‘Contains fluorinated greenhouse gases’(GWP 675).
1. Entering/leaving water temperature user side 30/35 °C, Entering external exchanger
air temperature 7 °C (R.H. = 85%).
2. COP (EN 14511:2018) Heating performance coecient. Ratio between delivered
heating capacitu and power input in compliance with EN 14511:2018.
3. Entering/leaving water temperature user side 40/45 °C, Entering external exchanger
air temperature 7 °C (R.H. = 85%).
4. Entering/leaving water temperature user side 47/55 °C, Entering external exchanger
air temperature7 °C (R.H. = 85%).
5. Entering/leaving water temperature user side 23/18 °C, Entering external exchanger
air temperature 35 °C.
6. EER (EN 14511:2018) cooling performance coecient. Ratio between delivered
coolimg capacitu and power input in compliance with EN 14511:2018.
7. User side entering/leaving water temperature 12/7 °C, external exchanger entering
air 35°C.
8. Seasonal Space Heating Energy Eciency Class according to Commission delega-
ted Regulation (EU) No 811/2013. W = Water outlet temperature (°C).
9. Data referred to unit operation with inverter frequency optimized for this application.
10. Data calculated according to the EN 14825:2016 Regulation.
