CLIVET WSHN-EE 101 User Manual

pag 50
Size 61-121
Size 61 71 81 91 101 121 (1) COMPRESSOR
(2) INTERNAL EXCHANGER = UTILITY SIDE EXCHANGER
(3) EXTERNAL EXCHANGER = SOURCE SIDE EXCHANGER
(4) ELECTRICAL PANEL
(5) INTERNAL EXCHANGER WATER INLET
(6) INTERNAL EXCHANGER WATER OUTLET
(7) EXTERNAL EXCHANGER WATER INLET
(8) EXTERNAL EXCHANGER WATER OUTLET
(9) SANITARY WATER OUTLET 1"F GAS (OPTIONAL)
(10) UTILITY SIDE PUMP (STANDARD)
(11) EXPANSION VESSEL
(12) WATER SIDE SAFETY VALVE
(13) SOURCE SIDE PUMP (OPTIONAL)
(14) 3 WAYS-VALVE (OPTIONAL)
(15) CLEARANCE ACCESS RECOMMENDED
(16) POWER INPUT
(17-19) 1/2" GAS CHARGE FITTING (SIZES 61-71-81-91)
(18-19) 1/2" GAS CHARGE FITTING (SIZES 101-121)
(G) BARYCENTRE
M mm 154 167 178 185 187 189
N mm 213 200 191 182 180 178
O mm 286 300 330 336 339 334
P mm 227 213 186 177 174 179
Length mm 573 573 573 573 573 573
Length mm 604 604 604 604 604 604
Height mm 858 858 858 858 858 858
W1 kg 20 30 44 56 58 61
W2 kg 45 47 53 54 54 53
W3 kg 15 20 23 27 27 30
W4 kg 35 32 27 26 25 26
Operating weight kg 115 129 147 163 164 170
Shipping weight kg 112 126 143 159 160 166
W1
W2
W4
W3
573
604
80 100 80 8050
M N
46
1
1
1
3
2
4
4
5 6 78 9
13
10
11
29.551329.5
(15)
600
(15)
150
14
10
(15)
150
OP
858
107.5 367 127.5
16
"G"
12
17
18
52
120
51
108
19
