CLIVET WSN-XIN 101 User Manual

M0V940M13-06 WSN-XIN 21-141 19
A Signals B RS485 C Power supply
AP1 Main control module FU-V Fan fuse
AP2 Electronic thermostatic management FU1 230V aux. cicuit fuse
AP6 RS 485 module
(OPTIONAL)
FU2 compressor overload protection and timer
T1 Transformer QS1 Main isolator switch
FU1 compressor overload protection and timer
Size 51-71
QM1 Compressor line protection
FU2
230V aux. cicuit fuse
Size 51-71
KA1 Inverter alarm auxiliary relay
KA2 Compressor control relay
KA3 Ciculation pump control relay
XT1 Terminal block of the customer connections
