INTRODUCTION
All
CMT
portable tools conform with standard
EN
50144, CE 98/37 machine directives
and following
modifi cations, with
EEC 73/23, EEC 93/68
and, with regard
to electromagnetic compatibility, the tools conform with
directive
EEC 89/336, and with standards EN 55014-1,
EN 55014-2, EN 61000-3-2, EN 61000-3-3
.
The
mark on the tool guarantees its
conformity.
conformity.
conformity.
If used with the care and serviced regularly, this tool will
provide long-lasting and reliable service.
Carefully follow the instructions contained in this manual,
using them for reference for any eventual controls that may
need to be carried out.
1 GENERAL INFORMATION
1.0 THE AIM OF THIS MANUAL
This manual has been compiled by the manufacturer and
is an integrative part of the tool equipment.
The information contained is for the benefi t of professional
operators.
This manual defi nes the aims for which the tool has been
constructed and contains all the necessary information to
guarantee correct and safe use.
It is therefore strongly recommended that this manual
is consulted before performing any kind of adjustment
operation, use or maintenance tasks.
Constant observance of the standard regulations
contained in this manual will guarantee both machine and
operator safety, economic working and longer functional
operation of the tool itself.
Photographs and drawings have been supplied by the
constructor for exemplifying purposes.
With the aim of following a policy of constant development
and product modernization, the constructor is entitled to
make modifi cations without forewarning.
1.1 TOOL IDENTIFICATION
The plate located on the left hand side of the tool identifi es
the model, the data plate located on the right hand side
of the tool contains the model references, the technical
specifi cations of the motor and the constructor.
1.1.1 IDENTIFICATION
(fi g.1)
A Logotype plate
B Data plate
C Handgrip
D Switch
E Depth regulation knob
F Parallel guide
G Clamping knob
H Switch unlocking push-button
I Guard
2 TECHNICAL SPECIFICATIONS
2.1 TECHNICAL DATA
M
ODEL
CMT3
Voltage (V~) (*)
230-240
110
Current (A)
3,7
7,9
Frequency (Hz)
50-60
Absorbed power (W)
850
R.p.m. (unloaded) (min
-1
)
13000
R.p.m. fully-loaded (min
-1
)
9500
Plane dimensions (mm)
80x286
Cutting depth (mm)
0-3
Width of plane (mm)
82
Depth of rabbet (mm)
23
Weight (Kg)
2,8
Sound pressure emitted
Lpa (dB
A
) (**)
90
Sound power emited
Lwa (dB
A
) (**)
103
Vibration level (m/s
2
) (**)
3,2
Insulation class
/
II
* See paragraph 4.3
** Surveys carried out according to standards:
EN 50144.1 - EN 50144.2.14
2.2 STANDARD EQUIPMENT:
Parallel adjustable inclined guide, graduated support,
service spanner.
The series fi ttings may vary according to the model
purchased and the actual commercial situation.
2.3 ACCESSORIES AVAILABLE ON REQUEST:
Blades, Suction union, Suction unit, kit for suction unit,
stationary support.
2.4 SAFETY STANDARDS
The tool has been designed and constructed to permit
operation in all situations and in absolute safety.
In particular working conditions remember to use
protective gloves and safety goggles.
INSTRUCTION MANUAL FOR
PORTABLE ELECTRIC PLANER
