Engine-Engineandcrankcase
-Intermediatering
1.470-1.500mm(0.058-0.059in)
-Oilcontrolring4.970-4.990mm(0.196-0.196in)
Clearancebetweenpistonringsandgrooves
-Combustionring0.100-0.120mm(0.004-0.005in)
-Intermediatering
0.050-0.100mm(0.002-0.004in)
-Oilcontrolring0.030-0.070mm(0.001-0.003in)
Pistonringendgapincylinderliners
-Combustionring0.40-0.50mm(0.016-0.020in)
-Intermediatering
0.65-0.80mm(0.026-0.031in)
-Oilcontrolring0.40-0.75mm(0.016-0.030in)
Connectingrod
Smallendbushhousing
-Nominal
59.000-59.030mm(2.323-2.324in)
Bigendbearinghousing
-Nominal
94.000-94.030mm(3.701-3.702in)
-Class194.000-94.010mm(3.701-3.701in)
-Class294.011-94.020mm(3.701-3.702in)
-Class394.021-94.030mm(3.702-3.702in)
Smallendbushdiameter
-Outside59.085-59.110mm(2.326-2.327in)
-Inside
54.019-54.035mm(2.127-2.127in)
Bigendbearingshellthickness
-Red
1.965-1.975mm(0.077-0.078in)
-Green1.976-1.985mm(0.078-0.078in)
-Yellow
1.986-1.995mm(0.078-0.079in)
Clearancebetweensmallendbushandhousing0.055-0.110mm(0.002-0.004in)
Clearancebetweenpistonpinandbush0.019-0.041mm(0.001-0.002in)
Connectingrodweight
-ClassA4753-4795g(167.7-169.1oz)
-ClassB4796-4835g(169.2-170.5oz)
-ClassC4836-4875g(170.6-172.0oz)
Maximumconnectingrodaxismisalignment
tolerance
0.08mm(0.003in)
Crankshaft
Mainjournals
-Ratedvalue
99.970-100.000mm(3.9358-3.9370in)
-Class199.970-99.979mm(3.9358-3.9362in)
-Class299.980-99.989mm(3.9362-3.9366in)
-Class399.990-100.000mm(3.9366-3.9370in)
Crankpins
-Ratedvalue
89.970-90.000mm(3.5421-3.5433in)
-Class189.970-89.979mm(3.5421-3.5425in)
-Class289.980-89.989mm(3.5425-3.5429in)
-Class389.990-90.000mm(3.5429-3.5433in)
Mainbearingshells
-Red
3.110-3.120mm(0.1224-0.1228in)
-Green3.121-3.130mm(0.1229-0.1232in)
-Yellow
3.131-3.140mm(0.1233-0.1236in)
Mainbearinghousings
-Ratedvalue
106.300-106.330mm(4.1850-4.1862in)
-Class1106.300-106.309mm(4.1850-4.1854in)
-Class2106.310-106.319mm(4.1854-4.1858in)
-Class3106.320-106.330mm(4.1858-4.1862in)
Clearancebetweenbearingshellsandmainjournals0.060-0.100mm(0.0024-0.0039in)
Clearancebetweenbearingshellsandbigends0.050-0.090mm(0.0020-0.0035in)
4786998101/05/2015
10.1[10.001]/4
