Engine-Engineandcrankcase
-Injector
46.000-46.016mm(1.8110-1.8117in)
Bushingoutsidediameterforrockerarms
-Intake
45.090-45.130mm(1.7752-1.7768in)
-Exhaust
59.100-59.140mm(2.3268-2.3283in)
-Injector
46.066-46.091mm(1.8136-1.8146in)
Bushinginsidediameterforrockerarms
-Intake
42.025-42.041mm(1.6545-1.6552in)
-Exhaust
56.030-56.049mm(2.2059-2.2067in)
-Injector
42.015-42.071mm(1.6541-1.6563in)
Clearancebetweenbushingsandhousings
-Intake
0.074-0.130mm(0.0029-0.0051in)
-Exhaust
0.081-0.140mm(0.0032-0.0055in)
-Injector
0.050-0.091mm(0.0020-0.0036in)
Clearancebetweenbushingsofrockerarmsand
shaft
-Intake
0.025-0.057mm(0.0010-0.0022in)
-Exhaust
0.025-0.057mm(0.0010-0.0022in)
-Injector
0.015-0.087mm(0.0006-0.0034in)
