CNH Cursor 9 - Page 27

Engine-Engineandcrankcase
PistonpinOD-pinbore0.016-0.028mm(0.0006-0.0011in)
Pistonringgrooves
-Top
2.582-2.716mm(0.102-0.107in)
-Middle
2.550-2.570mm(0.100-0.101in)
-Bottom
4.02-4.04mm(0.158-0.159in)
Pistonrings
-Combustionring2.429-2.473mm(0.096-0.097in)
-Intermediatering
2.470-2.500mm(0.097-0.098in)
-Oilcontrolring3.970-3.990mm(0.156-0.157in)
Clearancebetweenpistonringsandgrooves
-Combustionring0.109-0.287mm(0.004-0.011in)
-Intermediatering
0.050-0.100mm(0.002-0.004in)
-Oilcontrolring0.030-0.070mm(0.001-0.003in)
Pistonringendgapincylinderliners
-Combustionring0.3-0.4mm(0.012-0.016in)
-Intermediatering
0.60-0.75mm(0.024-0.030in)
-Oilcontrolring0.35-0.65mm(0.014-0.026in)
Connectingrod
Smallendbushhousing
-Nominal
55.700-55.730mm(2.193-2.194in)
Bigendbearinghousing
-Nominal
85.987-86.013mm(3.385-3.386in)
-Class185.987-85.996mm(3.385-3.386in)
-Class285.997-86.005mm(3.386-3.386in)
-Class386.006-86.013mm(3.386-3.386in)
Smallendbushingdiameter
-Outside55.780-55.820mm(2.196-2.198in)
-Inside
52.015-52.030mm(2.048-2.048in)
Bigendbearingshellthickness
-Red
1.994-2.002mm(0.079-0.079in)
-Green2.002-2.010mm(0.079-0.079in)
-Yellow
2.010-2.018mm(0.079-0.079in)
Clearancebetweensmallendbushand
housing
0.05-0.12mm(0.002-0.005in)
Clearancebetweenpistonpinandbushing0.015-0.036mm(0.001-0.001in)
Connectingrodweight
-ClassA3308-3338g(116.7-117.7oz)
-ClassB3339-3368g(117.8-118.8oz)
-ClassC3369-3398g(118.8-119.9oz)
Maximumconnectingrodaxismisalignment
tolerance
0.08mm(0.003in)
Crankshaft
Mainjournals
-Ratedvalue
92.970-93.000mm(3.6602-3.6614in)
-Class192.970-92.979mm(3.6602-3.6606in)
-Class292.980-92.989mm(3.6606-3.6610in)
-Class392.990-93.000mm(3.6610-3.6614in)
Crankpins
-Ratedvalue
81.915-81.945mm(3.225-3.226in)
-Class181.915-81.924mm(3.225-3.225in)
-Class281.925-81.934mm(3.225-3.226in)
-Class381.935-81.945mm(3.226-3.226in)
Mainbearingshells
-Red
2.968-2.978mm(0.117-0.117in)
-Green2.978-2.988mm(0.117-0.118in)
-Yellow
2.988-2.998mm(0.118-0.118in)
