Engine-Engineandcrankcase
Camshaftbearingjournals64.924-64.940mm(2.556-2.557in)
O.D.ofthecamshaftbushings69.090-69.130mm(2.720-2.722in)
I.D.ofthecamshaftbushings65.080-65.116mm(2.562-2.564in)
Clearancebetweenbushingsandhousingsin
thecylinderhead
0.060-0.115mm(0.002-0.005in)
Clearancebetweenbushingsandbearing
journals
0.050-0.122mm(0.002-0.005in)
Camlift
-Intakelobe
7.4034mm(0.2915in)
-Exhaustlobe
8.2108mm(0.3233in)
Diameteroftherockershaft31.964-31.980mm(1.258-1.259in)
Bushinghousingintherockerarms
-Intake
32.025-32.041mm(1.261-1.261in)
-Exhaust
32.025-32.041mm(1.261-1.261in)
Clearancebetweenbushingsandhousings
-Intake
0.074-0.130mm(0.0029-0.0051in)
-Exhaust
0.081-0.140mm(0.0032-0.0055in)
-Injector
0.050-0.091mm(0.0020-0.0036in)
Clearancebetweenbushingsofrockerarms
andshaft
-Intake
0.045-0.077mm(0.002-0.003in)
-Exhaust
0.045-0.077mm(0.002-0.003in)
