CARAVAN EQUIPMENT
4. Closing the blinds:
a) Pull blind across aperture using finger grip
in the bar. Engage with plastic clip on the
other side of the aperture.
CAUTION In extremely bright sunshine, the
blackout blind must only be closed two-
thirds, and the pane must be set in the
intermediate position.
b) Select the required position (black-
out/flyscreen) by moving both joined end
rods together.
5. Opening the blinds:
a) Move blind (end rod with rocker) right to
the outside.
b) Hold the recessed grip with one hand;
with the other hand, press the rocker and
move the blind back (do not let it recoil).
• Suitable for a max. of 100km/h (62.5mph)
(with Seitz spoiler up to 130km/h (81mph).
• Do not stand on the acrylic glass dome.
• Close HEKI 2 completely before moving off.
• Do not leave your caravan when HEKI 2 is
open.
• Please consult your supplying dealer if
you have any problems or defects.
• Remove any snow/ice or dirt before
opening the roof.
Opening / closing the dome:
- press the push button (1) and
simultaneously open the dome with the
bar (2).
Position “A”
- push the bar (2) to the marked rest
position ( ).
- Fix the bar in the rest position by
pushing the sliders (3), left and right,
downwards.
Position “B”
- push the bar (2) to the marked position
( ) and lead over the locking mechanism
left and right by applying slight pressure.
Position “C”
- push the bar (2) to the marked rest
position ( ).
- applying slight pressure, lead the bar
(2) over the catch hook (4) left and right
so that the dome is locked and the bar
(2) lies on the push button (1).
Position “D”
- push the bar (2) to the marked position ( )
Opening / closing the blinds
- push the blind (5) in the direction of the
arrow (A) and the flyscreen (6) in the
direction of the arrow (B).
