ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2. This product is for home use only and not intended for commercial establishments.
COASTERFURNITURE.COM
PAGE 3 OF 6
ITEM:
Z-B1 (BOX 1) - HARDWARE PACK IS LOCATED IN 222831F (B1)
HARDWARE IDENTIFICATION
1
BOLT 1
(M8 x 16mm - RBW)
8PCS
2
6PCS
4
6PCS
5
6PCS
6
8
1PC
1PC
9
SMALL ALLEN
WRENCH
(M4 x 65MM - BLK)
FLAT HEAD SCREW
(M4 x 32MM - RBW)
3
8PCS
BOLT 3
(M8 x 35mm - RBW)
BOLT 4
(M6 x 35mm - RBW)
BIG ALLEN
WRENCH
(M5 x 65MM - BLK)
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provided this item.
7
8PCS
4PCS
BOLT 2
(M6 x 40mm - RBW)
BIG LOCK WASHER
10
1PC
11
12
8PCS
8PCS
BIG FLAT WASHER
SMALL LOCK WASHER
SMALL FLAT WASHER
(5/16" x 14ø - RBW)
(5/16" x 22ø - RBW)
(1/4" x 19ø - RBW)
(1/4" x 12ø - RBW)
ADAPTOR PLUG
222831F(B1&B2)
To Next Page
