ASSEMBLY INSTRUCTIONS
935923
ITEM:
HARDWARE IDENTIFICATION
10PCS
1
LARGE CAM BOLT
(38MM)
14PCS
10
23PCS
LARGE CAM-LOCK
(∅15MM)
LARGE WOOD DOWEL
(8 x 30mm)
2
11
3
12PCS
LONG BOLT
(1/4" x 35mm SR)
12
12PCS
1PC
6PCS
SHORT FAST SCREW
( 8 x 25mm)
SMALL BOLT
(5/32" x10mm)
GLUE
4
13
5
1PC
ALLEN WRENCH
(4mm)
14
3PCS
HANDLE BOLT
(5/32" x22mm)
6
15
7
16
8
17
8PCS
SUCTION CUP
9
18
10PCS
SMALL CAM BOLT
4PCS
CAP
(20 x 30mm)
19
6PCS
SMALL CAM-LOCK
(∅12mm)
6PCS
SMALL WOOD DOWEL
(6 x 25mm)
Hardware pack is located in 935923B2
8PCS
LONG FAST SCREW
( 8 x 45mm)
8PCS
PLASTIC WASHER
(∅15mm)
8PCS
WASHER
(∅16mm)
8PCS
SHORT BOLT
(1/4" x 25mm SR)
8PCS
COVER
20
21
4PCS
SHORT SCREW
(4 x 28mm)
4PCS
MEDIUM FAST SCREW
( 8 X 38mm)
